Hotel Key Cards Compatible With Onity
Onity DirectKey, Advance, HT & Trillium electronic locks.
The direct answer
Yes — American Hotel Cards supplies RFID key cards compatible with Onity DirectKey and Advance locks. They use MIFARE chips on the 13.56 MHz ISO/IEC 14443-A standard, in CR80 format, custom-printed and shipped blank for your front desk to encode — or pre-programmed to your profile. Older Onity HT-series doors were magnetic-stripe, and we supply magstripe and combo cards for those.
Overview
How Onity reads a key card
Onity (now part of Carrier) is the third of the three lock brands that dominate U.S. hotel doors. Its current RFID platforms — Onity DirectKey and Onity Advance — read contactless 13.56 MHz credentials in the MIFARE family, and DirectKey adds Bluetooth mobile-key support alongside the physical card. Cards we supply for these locks are standard CR80 RFID cards with the chip matched to your reader configuration.
The long-running Onity HT-series (HT24, HT28 and similar) were magnetic-stripe locks and remain in service at many properties. If your doors take a swipe, you are on an HT-series Onity, and we supply HiCo magnetic-stripe cards — or combo cards with both a magstripe and an RFID inlay for properties moving from HT to DirectKey/Advance in phases.
On the RFID platforms, your own Onity system and front-desk encoder write the credential — room, dates and access rights — at check-in. We supply the blank or printed card; you program it. That keeps the access security entirely on your side, and means we provide compatible card stock rather than ever copying a guest’s active card.
Card specification
The Onity-compatible card, in detail
MIFARE Classic / DESFire (13.56 MHz)
| Chip | MIFARE Classic 1K · MIFARE DESFire (matched to your DirectKey / Advance config) |
|---|---|
| Protocol | ISO/IEC 14443-A |
| Frequency | 13.56 MHz |
| Mobile key | DirectKey supports Bluetooth mobile keys alongside the physical card |
| Legacy option | Magnetic stripe (HiCo) for Onity HT-series doors; RFID + magstripe combo |
| Format | CR80 — 85.6 × 54 mm (0.76 mm / 30 mil) |
| Encoding | Blank for on-site encoding, or pre-encoded to your profile |
| Printing | Full-bleed CMYK, Pantone, metallic foil, spot UV, sequential numbering |
| MOQ | From 500 cards |
| Lead time | Approx. 2–3 weeks after artwork approval |
How encoding works
Onity RFID credentials are written by your own Onity system and front-desk encoder, not by us. We supply the blank or custom-printed card; your property programs the room, dates and access at check-in. On DESFire configurations the credential is encrypted and cannot be cloned, so on-site encoding on your own system is the secure path. We provide compatible stock for your system to encode and never copy a live guest card.
What we make for Onity
We supply cards compatible with Onity DirectKey and Onity Advance (13.56 MHz MIFARE, encoded on your Onity system), plus magnetic-stripe and RFID+magstripe combo cards for legacy Onity HT24/HT28 and Trillium doors. Send us your lock model or a sample card and we will confirm the exact chip before you order.
Ordering tips
- A swipe at the front desk means legacy HT-series magstripe; a tap means DirectKey/Advance RFID — that one observation tells us most of what we need.
- If you are rolling out DirectKey mobile keys, pair them with NFC fallback cards so no guest is ever locked out by a dead phone.
Recommended cards
Cards we recommend for Onity
Every one carries the right credential for your locks — choose the material and finish that fits your property.
RFID Hotel Key Cards
MIFARE® & NFC key cards encoded for any U.S. hotel lock system.
View product
NFC & Mobile-Key Cards
Tap-to-enter NFC cards that bridge plastic and mobile-key rollouts.
View product
Custom Printed Key Cards
Full-bleed CMYK, metallic foil, spot UV and Pantone brand matching.
View product
Eco Wood RFID Hotel Key Cards
FSC®-certified maple, walnut & birch cards with a natural, warm feel.
View productQuestions
Onity compatibility, answered
What key cards work with Onity locks?
Onity RFID locks — DirectKey and Advance — read 13.56 MHz MIFARE cards (Classic or DESFire). American Hotel Cards supplies exactly those in CR80 format, custom-printed and encoded blank or to your profile. Older Onity HT-series doors are magnetic-stripe, and we supply magstripe or combo cards for those instead.
Can you copy or duplicate our existing Onity cards?
No. We supply compatible blank or custom-printed cards that your own Onity system encodes with each guest’s room and dates. On DESFire configurations the credential is encrypted and cannot be cloned anyway — which is the point. We never copy a live guest card; you keep full control of access.
What chip and technology does Onity use?
Current Onity RFID locks (DirectKey, Advance) operate at 13.56 MHz on ISO/IEC 14443-A using MIFARE chips; DirectKey also supports Bluetooth mobile keys. The legacy HT-series used a magnetic stripe. We match the card to whichever your doors read.
Can you print our branding on Onity-compatible cards?
Yes. Onity-compatible cards are fully custom — full-bleed CMYK, Pantone matching, metallic foil, spot UV, signature panels and sequential numbering — all as surface finishes that do not affect how the lock reads the card.
What is the minimum order for Onity-compatible cards?
Minimums start at 500 cards, with most custom orders shipping in roughly 2–3 weeks after artwork approval. Reorders and plain stock are typically faster; tell us your timeline and we will plan around it.
We run Onity DirectKey with mobile keys — do we still need cards?
Almost always, yes. Mobile-key adoption is never 100% — guests skip the app, run out of battery or use unsupported phones — so a physical DirectKey-compatible card (or an NFC card) is the dependable fallback at the door. Many properties keep both.
Ready when you are
Get Onity-compatible cards made for your property
Request a free sample pack to test the chip and the print against your own Onity doors, or send us your lock model and quantity for a tailored quote. We confirm compatibility before anything prints.
